Charge air · 993-CA-CHARGE-PIPE-SET-PET-0001

993 Turbo charge-air tract transcribed parts (group 107-45) - PET-transcribed identity set

ConceptNon-critical trim

Identity-only catalogue record grouping the charge-air (group 107-45, 'charge air cooler') line items transcribed per-line from the local PET transcriptions and relevant to the M64 charge-air subsystem: charge air cooler 993 110 330 53 (pos 1), air guide 993 110 340 53 and 993 110 340 54 (pos 2), bracket 993 110 110 50 and 993 110 110 52 (pos 5), sleeve 993 110 111 50 (pos 10), temperature sensor 993 606 114 00 (pos 12), pressure hoses 993 110 633 56 and 993 110 632 56 (pos 19), with their clamps 999 512 648 02 and 999 512 647 02 (pos 20/21). Both independent catalogue transcriptions (KAT 17 and Porsche Classic KAT 517 USA) agree on these positions and numbers. No dimensions, flow cross-sections, pressure ratings or geometry are claimed.

Catalogue status card for 993-ca-charge-pipe-set-pet-0001: no part geometry depicted.
Catalogue study only. No CAD geometry is available for this record. Status card; no part geometry depicted.

The design

Vehicle
Porsche 993, 1995–1998
Variants
993 Turbo
Porsche part numbers
99311033053, 99311034053, 99311034054, 99311011050, 99311011052, 99311011150, 99360611400, 99311063356, 99311063256
Category
Charge air cooler plumbing
Geometry basis
Estimated
Preferred process
Not chosen yet
Other candidate processes
CNC machining
Material
unknown per line item (hoses are rubber/composite assemblies per the PET description 'pressure hose')
Material standard
not recorded

Known limits

  • Identity only: the PET carries part number, position, description and (in the Austria read) quantities, no dimensions, pressure ratings or flow data.
  • Suffix variants -53/-54 (air guide) and -50/-52 (bracket) are transcribed as listed without asserting which fits which build date or supersession.
  • The intercooler core cross-referenced by an aftermarket supplier (260x270x60 mm declared) is a replacement-product envelope, not OEM geometry.
  • Left/right assignment of the two pressure hoses at pos 19 is by the FVD product pages (633 = left, 632 = right); the PET line itself lists both at position 19 without a side annotation.

What a supplier would have to provide

  • Professional engineering review before any manufacturing claim
  • Dimensional inspection on a real part before any geometry work
